4 x XLR/TRS “combo jack” mic/line/Hi-Z guitar inputs Independent preamp gain, 48V phantom power and monitor switch for each input
Analog inputs
2 x 1/4″ line in
Analog outputs
4 x 1/4″ TRS line out (balanced, DC coupled)
2 x 1/4″ TRS stereo headphone with independent volume
Computer I/O
1 x USB-C 2.0 audio class compliant Compatible with USB Type A host (“see power below) USB C-to-C and C-to-A cables included
1 x MIDI IN
1 x MIDI OUT
16 MIDI channels to/from computer host
Headphones
2 x 1/4″ TRS stereo headphone with independent volume
1 x 3-4 switch for optional monitoring of Line Out 3-4
Phantom power
4 x individual +48V
Front panel
2 x 1/4″ TRS headphone output
1 x potentiometer. monitor vol
2 x potentiometer. phone vol
1 x potentiometer input monitor mix
4 x potentiometer mic/line/guitar input gain
11 x switches (4) 48V, (5) ΜΟΝ, (1) A/B and (1) 3-4 160 x 128 pixel full-colored LCD with input and output level meters
Power
Bus-powered through USB*
Optional multi-blade international 15V DC power adapter (included), 1.0A max tip pos or neg, supports 100-240V power sources (US/Japan, EU, UK, Australia)
*USB bus power available with USB-C hosts only. For other hosts, use the included DC power adapter. For iOS devices with a Lightning port, an Apple Lightning to USB3 Camera Adapter is required (sold separately).
Dimensions and weight
(width x depth x height, enclosure only)
9.21 x 4.75 x 1.8 inches
23.4 x 12.0 x 4.57 cm
2.15 lbs/0.975 kg
