| Sound Generator |
| Maximum Polyphony |
256 voices |
| Parts |
16 parts |
| Tones |
Tones: 433 + 256 (GM2)
Drum Sets: 9 + 9 (GM2) |
| Effects |
Equalizer: 6 types
Reverb: 11 types
Chorus: 12 types |
| Mic Effects |
3-Band Equalizer
Reverb: 11 types
Chorus: 12 types
Delay: 2 types
Other: 5 types |
| Keyboard |
| Keyboard |
61 keys (with velocity) |
| Touch Sensitivity |
Key Touch: 3 types, fixed touch |
| Speaker System |
| Speakers |
Speakers: 12 cm (4-3/4 inches) x 2
Tweeters: 3 cm (1-1/4 inch) x 2 |
| Rated Power Output |
10 W x 2 |
| Arranger |
| Styles |
Preset: 300 styles |
| Tempo |
30–280 |
| One Touch Setting |
4 settings/style |
| Registration |
8 banks x 4 memories |
| Controls |
START/STOP, INTRO/ENDING, FADE IN/OUT, FILL 1/3, FILL 2/4, CHORD, SYNC |
| Scale Tunings |
| Scale Recall |
12 user scale memories |
| User Scale Buttons |
Quarter-tone tuning
Tuning range: -50–+50 cent
* Capable save as user setting. |
| Audio Pads |
| Audio Pads |
12 pads for Audio playbacker via USB flash drive |
| Data Type |
MP3: 44.1 kHz, 32 kbps–320 kbps
WAV: 48 kHz/44.1 kHz/22 kHz, 16-bit linear format |
| Bluetooth |
| Bluetooth |
Audio: Bluetooth Ver 5.0 |
| Song |
| Demo Songs |
1 song |
| Recorder |
10 songs |
| Data playback |
Audio File (WAV: 48 kHz/44.1 kHz/22 kHz, 16-bit linear format, MP3: 44.1 kHz, 32 kbps–320 kbps, requires USB flash drive) |
| Convenient Functions |
| Convenient Functions |
Metronome (Adjustable Tempo/Beat/Volume)
Transpose (Keyboard: in semitones)
Dual
Split (Split point adjustable)
Speaker Auto Mute
Auto Off |
| Other |
| Connectors |
PHONES jack: stereo 1/4-inch phone type
MIC INPUT jack: 1/4-inch TRS phone type
OUTPUT (L/MONO, R) jacks: 1/4-inch phone type
PEDAL jack: 1/4-inch phone type
USB COMPUTER port: USB B type
USB MEMORY port: USB A type
DC IN jack |
| Controllers |
Pitch bend wheel |
| Display |
Custom LCD |
| Power Supply |
AC adaptor |
| Power Consumption |
30 W (When using the included AC adaptor) |
| Accessories |
Owner’s manual
Leaflet “USING THE UNIT SAFELY”
AC adaptor
Music rest |
| Options (sold separately) |
Pedal switch: DP series |
| Size and Weight |
| Width |
With music rest:
1,048 mm
41-17/64 inchesWithout music rest:
1,048 mm
41-17/64 inches |
| Depth |
With music rest:
461 mm
18-5/32 inchesWithout music rest:
391 mm
15-25/64 inches |
| Height |
With music rest:
319 mm
12-9/16 inchesWithout music rest:
141 mm
5-35/64 inches |
| Weight (excluding AC adaptor and music rest) |
9.6 kg
21 lbs 3 oz |
