Mixer Yamaha Rio 1608-D2

Được xếp hạng 0.0 5 sao

(đánh giá) Đã bán 172

		Rio1608-D2
Sampling frequency rate	External	44.1 kHz, 48 kHz, 88.2 kHz, 96 kHz, +4.1667%, +0.1%, –0.1%, –4.0% (±200 ppm)
Signal delay		Less than 1.7 ms, Rio INPUT to Rio OUTPUT connect with PM10 using Dante, Fs= 96 kHz, Dante Receive Latency set to 0.25 msec
Total harmonic distortion		Less than 0.05% 20 Hz-20 kHz@+4 dBu into 600Ω, Fs= 48 kHz, Less than 0.05% 20 Hz-40 kHz@+4 dBu into 600Ω, Fs= 96 kHz, INPUT to OUTPUT, Input Gain= Min.
Frequency response		+0.5, –1.5 dB 20 Hz-20 kHz, refer to +4 dBu output @1 kHz, INPUT to OUTPUT, Fs= 48 kHz / +0.5, –1.5 dB 20 Hz-40 kHz, refer to +4 dBu output @1 kHz, INPUT to OUTPUT, Fs= 96 kHz
Dynamic range		112 dB typ., DA Converter, 108 dB typ., INPUT to OUTPUT, Input Gain= Min.
Hum & noise level	Equivalent input noise	–128 dBu typ., Input Gain= Max.
Hum & noise level	Residual output noise	–88 dBu, ST master off
Crosstalk		-100dB, adjacent INPUT/OUTPUT channels, Input Gain = -6dB, @1 kHz *Measured with a 30dB/octave filter @22kHz
Power requirements		100-240V, 50/60Hz
Power consumption		72W
Dimensions	W	480 mm (18.9″)
	H	132 mm (5.2″)
	D	368 mm (14.5″)
Net weight		9.6 kg (21.2 lbs)
Accessories		Owner’s Manual, AC power cord (250cm)
Others		NC Value: FAN MODE LOW: NC=15 / HIGH: NC=25 (Measurement position: 1 m from the front of the unit), Operating temperature range: 0 – 40°C, Storage temperature range: –20 – 60°C

SKU: RIO1608D2 Danh mục: Bàn Trộn - Mixer, Bàn Mixer Yamaha Thương hiệu: Yamaha

		Rio1608-D2
Sampling frequency rate	External	44.1 kHz, 48 kHz, 88.2 kHz, 96 kHz, +4.1667%, +0.1%, –0.1%, –4.0% (±200 ppm)
Signal delay		Less than 1.7 ms, Rio INPUT to Rio OUTPUT connect with PM10 using Dante, Fs= 96 kHz, Dante Receive Latency set to 0.25 msec
Total harmonic distortion		Less than 0.05% 20 Hz-20 kHz@+4 dBu into 600Ω, Fs= 48 kHz, Less than 0.05% 20 Hz-40 kHz@+4 dBu into 600Ω, Fs= 96 kHz, INPUT to OUTPUT, Input Gain= Min.
Frequency response		+0.5, –1.5 dB 20 Hz-20 kHz, refer to +4 dBu output @1 kHz, INPUT to OUTPUT, Fs= 48 kHz / +0.5, –1.5 dB 20 Hz-40 kHz, refer to +4 dBu output @1 kHz, INPUT to OUTPUT, Fs= 96 kHz
Dynamic range		112 dB typ., DA Converter, 108 dB typ., INPUT to OUTPUT, Input Gain= Min.
Hum & noise level	Equivalent input noise	–128 dBu typ., Input Gain= Max.
Hum & noise level	Residual output noise	–88 dBu, ST master off
Crosstalk		-100dB, adjacent INPUT/OUTPUT channels, Input Gain = -6dB, @1 kHz *Measured with a 30dB/octave filter @22kHz
Power requirements		100-240V, 50/60Hz
Power consumption		72W
Dimensions	W	480 mm (18.9″)
	H	132 mm (5.2″)
	D	368 mm (14.5″)
Net weight		9.6 kg (21.2 lbs)
Accessories		Owner’s Manual, AC power cord (250cm)
Others		NC Value: FAN MODE LOW: NC=15 / HIGH: NC=25 (Measurement position: 1 m from the front of the unit), Operating temperature range: 0 – 40°C, Storage temperature range: –20 – 60°C
